DAS-P16 Pressure Scanner

The DAS-P16 pressure scanner integrates 16 high-precision silicon piezoresistive sensors

and features system-level temperature compensation. It is suitable for multipoint pressure

measurement of gases, liquids and gas-liquid mixtures, with customization available

for measuring special media such as hydrogen. The device supports multiple measurement

modes including absolute, gauge, and differential pressure, with an accuracy of ±0.05% FS.

The sensors are specially treated for robustness.

It supports 24-bit AD conversion, with a maximum single-channel sampling rate of

0–10,080 Hz and synchronous acquisition across all 16 channels, meeting dynamic pressure

measurement requirements. The device utilizes the TCP communication protocol and NTP

clock synchronization, ensuring multi-unit synchronization during operation. Data can be

timestamped for reliable traceability and lossless transmission.

The accompanying DTsoft software, developed in C#, provides functions such as waveform

display, channel selection, calibration, video monitoring, data storage and computation and

threshold setting, and supports SDK integration. The DAS-P16 can be networked with other

GENSORS testing devices (such as the DAS-T temperature scanner) to form a

multi-parameter distributed data acquisition system.

Product Advantages:

• 24-bit AD conversion

• DTsoft is a software that we have independently developed and fully control ourselves.

• System accuracy of up to ±0.05% FS

• True synchronous acquisition per channel (0-10,080 Hz)  not scanning

• Multi-unit synchronization supported via NTP

• Configurable for absolute, gauge or differential pressure modes

• Auto-start upon power-on
